Flameproof Rotary Switch Indirect Entry

Flameproof Rotary Switch Indirect Entry Specification

Thickness
3 mm (enclosure wall)

Cable Diameter
16-25 mm

Sealed
Yes

Surface Treatment
Corrosion Resistant Powder Coating

Product Type
Flameproof Rotary Switch

Material
Aluminium Alloy (LM6)

Application
Industrial Control

Contact Resistance
< 50 m

Insulation Resistance
> 100 Mega Ohms

Diameter
80 mm (Body)

Terminal Socket
Screw Terminals

Style
Rotary

Fittings
Indirect Entry

Rated Voltage
415V AC

Weight
Approx. 800 grams

Color
Grey / Silver

No. of Positions
2, 3, or 4 (customizable)

Ambient Humidity
Up to 95% RH (non-condensing)

Cover Fastening
SS Screws

Current Rating
32A

Ingress Protection
IP65

Switch Mechanism
Snap Action Contacts

Operating Temperature Range
-20°C to +60°C

Finish
Anti-corrosive

Enclosure Standard
IS/IEC 60079-1:2007

Cable Entry Type
Indirect side entry

Mounting Type
Panel/Wall Mount

Service Life
>10,000 Operations

Protection Class
Ex d IIA IIB

Gasket Type
Silicone Rubber

Flameproof Rotary Switch Indirect Entry Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Week

Delivery Time
3-5 Days

Main Domestic Market
All India

About Flameproof Rotary Switch Indirect Entry

This highly reliable flameproof rotary switch indirect entry that we are providing is applicable for controlling different types of electrical circuits. It is basically a switch which is operated by rotation. Our offered product is better than other traditional switches due to its greater pole. The input shaft of this component is coupled with motor for rotating motor shaft according to the turning of input gear. Flameproof rotary switch indirect entry possesses maximum working efficiency, hassle free performance, low maintenance, ruggedness and corrosion resistance. It is easy to mount as well as maintain and operate. Has a long lasting shine and high strength.

Superior Protection and Durability

This rotary switch is designed to offer flameproof protection (Ex d IIA IIB) and is rigorously tested to IS/IEC 60079-1:2007 standards. Its enclosure, built from LM6 aluminium alloy and finished with corrosion-resistant powder coating, ensures steadfast operation in harsh and hazardous industrial settings. The IP65 ingress protection rating and anti-corrosive properties make it dependable for long-term use.

Customizable Operation for Versatile Applications

With options for 2, 3, or 4 switch positions, this rotary switch caters to a wide range of industrial control needs. The snap action contact system ensures accurate and consistent switching, while the indirect side cable entry supports cable diameters from 16 to 25 mm. Its robust mechanical design is suited for both panel and wall mounting, allowing seamless integration into various industrial systems.

FAQs of Flameproof Rotary Switch Indirect Entry:

Q: How is the Flameproof Rotary Switch installed in industrial environments?

A: The switch is designed for both panel and wall mounting, offering flexibility for various industrial setups. The enclosure comes with pre-drilled provisions for mounting and is easily fastened in place using stainless steel screws, ensuring a secure installation.

Q: What are the key safety standards and certifications of this rotary switch?

A: This product meets the Ex d IIA IIB flameproof protection standard and is certified in accordance with IS/IEC 60079-1:2007, making it suitable for hazardous locations where inflammable gases may be present.

Q: When should I use a flameproof rotary switch with indirect entry?

A: This switch is ideal for use in industrial environments requiring high-level safety, such as chemical plants, refineries, or any location where there is a risk of explosive gas atmospheres. Indirect cable entry enhances sealing and minimizes the risk of ignition entry.

Q: Where can this rotary switch be used and who can supply it in India?

A: The switch is suitable for industrial control panels, machinery, or hazardous zone installations across India. It is available through authorized dealers, distributors, suppliers, traders, and wholesalers nationwide.

Q: What is the long-term benefit of using this rotary switch?

A: With anti-corrosive construction, powder-coated finish, robust silicone gaskets, and snap action contacts rated for over 10,000 operations, this switch offers durable, reliable performance with minimal maintenance needs.

Q: How does the indirect side cable entry function benefit my installation?

A: The indirect side entry allows safe and secure cable routing, accommodating cable diameters from 16 to 25 mm. This enhances the seals effectiveness, supporting the enclosures IP65 rating and contributing to the devices flameproof integrity.

Q: What makes the operation of this rotary switch efficient and secure?

A: The snap action switch mechanism ensures fast, dependable contact transitions with low contact resistance (under 50 m), while screw terminals guarantee steadfast electrical connections. The 3 mm thick enclosure and high insulation resistance further enhance overall safety and reliability.
